IDatasmithActorElement Class Reference

#include <IDatasmithSceneElements.h>

Inheritance diagram for IDatasmithActorElement:

Public Member Functions
virtual	~IDatasmithActorElement ()
virtual FVector	GetTranslation () const =0
virtual void	SetTranslation (double InX, double InY, double InZ, bool bKeepChildrenRelative=true)=0
virtual void	SetTranslation (const FVector &Value, bool bKeepChildrenRelative=true)=0
virtual FVector	GetScale () const =0
virtual void	SetScale (double InX, double InY, double InZ, bool bKeepChildrenRelative=true)=0
virtual void	SetScale (const FVector &Value, bool bKeepChildrenRelative=true)=0
virtual FQuat	GetRotation () const =0
virtual void	SetRotation (double InX, double InY, double InZ, double InW, bool bKeepChildrenRelative=true)=0
virtual void	SetRotation (const FQuat &Value, bool bKeepChildrenRelative=true)=0
virtual FTransform	GetRelativeTransform () const =0
virtual const TCHAR *	GetLayer () const =0
virtual void	SetLayer (const TCHAR *InLayer)=0
virtual void	AddTag (const TCHAR *InTag)=0
virtual void	ResetTags ()=0
virtual int32	GetTagsCount () const =0
virtual const TCHAR *	GetTag (int32 TagIndex) const =0
virtual void	AddChild (const TSharedPtr< IDatasmithActorElement > &InChild, EDatasmithActorAttachmentRule AttachementRule=EDatasmithActorAttachmentRule::KeepWorldTransform)=0
virtual int32	GetChildrenCount () const =0
virtual TSharedPtr< IDatasmithActorElement >	GetChild (int32 InIndex)=0
virtual const TSharedPtr< IDatasmithActorElement > &	GetChild (int32 InIndex) const =0
virtual void	RemoveChild (const TSharedPtr< IDatasmithActorElement > &InChild)=0
virtual const TSharedPtr< IDatasmithActorElement > &	GetParentActor () const =0
virtual void	SetIsAComponent (bool Value)=0
virtual bool	IsAComponent () const =0
virtual void	SetVisibility (bool bInVisibility)=0
virtual bool	GetVisibility () const =0
virtual void	SetCastShadow (bool bInCastShadow)=0
virtual bool	GetCastShadow () const =0
virtual void	SetMobility (EDatasmithActorMobilityType Mobility)=0
virtual EDatasmithActorMobilityType	GetMobility () const =0
Public Member Functions inherited from IDatasmithElement
virtual bool	IsA (EDatasmithElementType Type) const =0
virtual const TCHAR *	GetName () const =0
virtual void	SetName (const TCHAR *InName)=0
virtual const TCHAR *	GetLabel () const =0
virtual void	SetLabel (const TCHAR *InLabel)=0
virtual FMD5Hash	CalculateElementHash (bool bForce)=0
Public Member Functions inherited from DirectLink::ISceneGraphNode
virtual	~ISceneGraphNode ()=default
virtual TSharedPtr< FSceneGraphSharedState >	MakeSharedState () const
	Related nodes share a common object.
virtual TSharedPtr< FSceneGraphSharedState >	GetSharedState () const
UE_API void	SetSharedState (TSharedPtr< FSceneGraphSharedState > NewSharedState)
virtual const FParameterStore &	GetStore () const =0
	data
virtual FParameterStore &	GetStore ()=0
virtual void	CustomSerialize (class FSnapshotProxy &Ar)
void	CustomSerialize (class FSnapshotProxy &Ar) const
FSceneGraphId	GetNodeId () const
	References.
void	SetNodeId (FSceneGraphId Id)
UE_API void	RegisterReferenceProxy (class IReferenceProxy &View, FName Name)
UE_API int32	GetReferenceProxyCount () const
UE_API class IReferenceProxy *	GetReferenceProxy (int32 Index) const
UE_API FName	GetReferenceProxyName (int32 Index) const
UE_API FSceneGraphId	RegisterReference (ISceneGraphNode *Referenced)
UE_API void	UpdateRefs (class IReferenceResolutionProvider &Resolver, const FReferenceSnapshot &NewRefs)

Detailed Description

Base definition for Actor Elements like geometry instances, cameras or lights

Constructor & Destructor Documentation

~IDatasmithActorElement()

virtual IDatasmithActorElement::~IDatasmithActorElement ( )

inlinevirtual

Member Function Documentation

AddChild()

virtual void IDatasmithActorElement::AddChild ( const TSharedPtr< IDatasmithActorElement > &  InChild, EDatasmithActorAttachmentRule  AttachementRule = EDatasmithActorAttachmentRule::KeepWorldTransform  )

pure virtual

Adds a new child to the Actor Element

AddTag()

virtual void IDatasmithActorElement::AddTag ( const TCHAR *  InTag )

pure virtual

Add a new Tag to an Actor element

GetCastShadow()

virtual bool IDatasmithActorElement::GetCastShadow ( ) const

pure virtual

Get whether an actor's casts shadow

GetChild() [1/2]

virtual const TSharedPtr< IDatasmithActorElement > & IDatasmithActorElement::GetChild ( int32  InIndex ) const

pure virtual

GetChild() [2/2]

virtual TSharedPtr< IDatasmithActorElement > IDatasmithActorElement::GetChild ( int32  InIndex )

pure virtual

Get the InIndex-th child of the mesh actor

GetChildrenCount()

virtual int32 IDatasmithActorElement::GetChildrenCount ( ) const

pure virtual

Get the number of children on this actor

GetLayer()

virtual const TCHAR * IDatasmithActorElement::GetLayer ( ) const

pure virtual

Get the the name of the layer that contains this entity

GetMobility()

virtual EDatasmithActorMobilityType IDatasmithActorElement::GetMobility ( ) const

pure virtual

Get a mesh actor's visibility

GetParentActor()

virtual const TSharedPtr< IDatasmithActorElement > & IDatasmithActorElement::GetParentActor ( ) const

pure virtual

Get the parent actor of the Actor element, returns invalid TSharedPtr if the Actor is directly under the scene root

GetRelativeTransform()

virtual FTransform IDatasmithActorElement::GetRelativeTransform ( ) const

pure virtual

Returns the relative transform for this element

GetRotation()

virtual FQuat IDatasmithActorElement::GetRotation ( ) const

pure virtual

Get rotation (in quaternion format) of this entity

GetScale()

virtual FVector IDatasmithActorElement::GetScale ( ) const

pure virtual

Get absolute scale of this entity

GetTag()

virtual const TCHAR * IDatasmithActorElement::GetTag ( int32  TagIndex ) const

pure virtual

Get the 'TagIndex'th tag of an Actor element

GetTagsCount()

virtual int32 IDatasmithActorElement::GetTagsCount ( ) const

pure virtual

Get the number of tags attached to an Actor element

GetTranslation()

virtual FVector IDatasmithActorElement::GetTranslation ( ) const

pure virtual

Get absolute translation of this entity

GetVisibility()

virtual bool IDatasmithActorElement::GetVisibility ( ) const

pure virtual

Get a mesh actor's visibility

IsAComponent()

virtual bool IDatasmithActorElement::IsAComponent ( ) const

pure virtual

RemoveChild()

virtual void IDatasmithActorElement::RemoveChild ( const TSharedPtr< IDatasmithActorElement > &  InChild )

pure virtual

ResetTags()

virtual void IDatasmithActorElement::ResetTags ( )

pure virtual

Remove all Tags on the Actor element

SetCastShadow()

virtual void IDatasmithActorElement::SetCastShadow ( bool  bInCastShadow )

pure virtual

Set whether an actor's casts shadow

SetIsAComponent()

virtual void IDatasmithActorElement::SetIsAComponent ( bool  Value )

pure virtual

Indicates if this actor is a standalone actor or a component, when used in a hierarchy

SetLayer()

virtual void IDatasmithActorElement::SetLayer ( const TCHAR *  InLayer )

pure virtual

Set the the the layer that contains this entity, layer will be auto-created from its name

SetMobility()

virtual void IDatasmithActorElement::SetMobility ( EDatasmithActorMobilityType  Mobility )

pure virtual

Set a mesh actor's visibility

SetRotation() [1/2]

virtual void IDatasmithActorElement::SetRotation ( const FQuat &  Value, bool  bKeepChildrenRelative = true  )

pure virtual

Set rotation (in quaternion format) of this entity

SetRotation() [2/2]

virtual void IDatasmithActorElement::SetRotation ( double  InX, double  InY, double  InZ, double  InW, bool  bKeepChildrenRelative = true  )

pure virtual

Set rotation (in quaternion format) of this entity

SetScale() [1/2]

virtual void IDatasmithActorElement::SetScale ( const FVector &  Value, bool  bKeepChildrenRelative = true  )

pure virtual

Set absolute scale of this entity

SetScale() [2/2]

virtual void IDatasmithActorElement::SetScale ( double  InX, double  InY, double  InZ, bool  bKeepChildrenRelative = true  )

pure virtual

Set absolute scale of this entity

SetTranslation() [1/2]

virtual void IDatasmithActorElement::SetTranslation ( const FVector &  Value, bool  bKeepChildrenRelative = true  )

pure virtual

Set absolute translation of this entity

SetTranslation() [2/2]

virtual void IDatasmithActorElement::SetTranslation ( double  InX, double  InY, double  InZ, bool  bKeepChildrenRelative = true  )

pure virtual

Set absolute translation of this entity

SetVisibility()

virtual void IDatasmithActorElement::SetVisibility ( bool  bInVisibility )

pure virtual

Set a mesh actor's visibility

---

The documentation for this class was generated from the following file:

• Engine/Source/Runtime/Datasmith/DatasmithCore/Public/IDatasmithSceneElements.h
