UDocumentation UE5.7 10.02.2026 (Source)
API documentation for Unreal Engine 5.7
Public Member Functions | Friends | List of all members
UE::Geometry::Spline::ISplineInterface Class Referenceabstract

#include <SplineInterfaces.h>

+ Inheritance diagram for UE::Geometry::Spline::ISplineInterface:

Public Member Functions

virtual ~ISplineInterface ()=default

virtual void Clear ()=0

virtual TUniquePtr< ISplineInterface > Clone () const =0

virtual bool IsEqual (const ISplineInterface *OtherSpline) const =0

virtual FString GetValueTypeName () const =0

virtual FString GetImplementationName () const =0

virtual FInterval1f GetParameterSpace () const =0

virtual void SetClosedLoop (bool bClosed)=0

virtual bool IsClosedLoop () const =0

virtual FSplineTypeId::IdType GetTypeId () const =0

virtual int32 GetNumberOfSegments () const =0

virtual FInterval1f GetSegmentParameterRange (int32 SegmentIndex) const =0

virtual bool Serialize (FArchive &Ar)


Friends

FArchive & operator<< (FArchive &Ar, ISplineInterface &Spline)


Detailed Description

Interface for all spline types, where spline is defined as a piecewise continuous curve. Provides the base functionality independent of value type.

Constructor & Destructor Documentation

◆ ~ISplineInterface()

virtual UE::Geometry::Spline::ISplineInterface::~ISplineInterface ( )
virtualdefault

Member Function Documentation

◆ Clear()

virtual void UE::Geometry::Spline::ISplineInterface::Clear ( )
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TMultiSpline< SPLINETYPE >, UE::Geometry::Spline::TMultiSpline< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TPolyBezierSpline< VALUETYPE >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ Clone()

virtual TUniquePtr< ISplineInterface > UE::Geometry::Spline::ISplineInterface::Clone ( ) const
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TPolyBezierSpline< VALUETYPE >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ GetImplementationName()

virtual FString UE::Geometry::Spline::ISplineInterface::GetImplementationName ( ) const
pure virtual

Implemented in UE::Geometry::Spline::TMultiSpline< SPLINETYPE >, UE::Geometry::Spline::TMultiSpline< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, and UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >.

◆ GetNumberOfSegments()

virtual int32 UE::Geometry::Spline::ISplineInterface::GetNumberOfSegments ( ) const
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TPolyBezierSpline< VALUETYPE >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ GetParameterSpace()

virtual FInterval1f UE::Geometry::Spline::ISplineInterface::GetParameterSpace ( ) const
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TPolyBezierSpline< VALUETYPE >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ GetSegmentParameterRange()

virtual FInterval1f UE::Geometry::Spline::ISplineInterface::GetSegmentParameterRange ( int32  SegmentIndex) const
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TPolyBezierSpline< VALUETYPE >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ GetTypeId()

virtual FSplineTypeId::IdType UE::Geometry::Spline::ISplineInterface::GetTypeId ( ) const
pure virtual

Gets the type ID for this spline instance

Returns
Type ID that uniquely identifies this spline class/value type combination

Implemented in UE::Geometry::Spline::TMultiSpline< SPLINETYPE >, UE::Geometry::Spline::TMultiSpline< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TSplineInterface< VALUETYPE >, UE::Geometry::Spline::TSplineInterface< SPLINETYPE::ValueType >, and UE::Geometry::Spline::TSplineInterface< T >.

◆ GetValueTypeName()

virtual FString UE::Geometry::Spline::ISplineInterface::GetValueTypeName ( ) const
pure virtual

Implemented in UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TSplineInterface< VALUETYPE >, UE::Geometry::Spline::TSplineInterface< SPLINETYPE::ValueType >, and UE::Geometry::Spline::TSplineInterface< T >.

◆ IsClosedLoop()

virtual bool UE::Geometry::Spline::ISplineInterface::IsClosedLoop ( ) const
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ IsEqual()

virtual bool UE::Geometry::Spline::ISplineInterface::IsEqual ( const ISplineInterface *  OtherSpline) const
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TMultiSpline< SPLINETYPE >, UE::Geometry::Spline::TMultiSpline< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ Serialize()

virtual bool UE::Geometry::Spline::ISplineInterface::Serialize ( FArchive &  Ar)
inlinevirtual

Reimplemented in FNewSpline, UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TMultiSpline< SPLINETYPE >, UE::Geometry::Spline::TMultiSpline< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, UE::Geometry::Spline::TSplineInterface< VALUETYPE >, UE::Geometry::Spline::TSplineInterface< SPLINETYPE::ValueType >, UE::Geometry::Spline::TSplineInterface< T >, and UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >.

◆ SetClosedLoop()

virtual void UE::Geometry::Spline::ISplineInterface::SetClosedLoop ( bool  bClosed)
pure virtual

Implemented in UE::Geometry::Spline::TBSpline< VALUETYPE, DEGREE >, UE::Geometry::Spline::TBSpline< T, 1 >, UE::Geometry::Spline::TBSpline< VALUETYPE, 3 >, UE::Geometry::Spline::TSplineWrapper< SPLINETYPE >, UE::Geometry::Spline::TSplineWrapper< TPolyBezierSpline< VALUETYPE > >, UE::Geometry::Spline::TSplineWrapper< UE::Geometry::Spline::FTangentBezierSpline3d >, FNewSpline, UE::Geometry::Spline::TTangentBezierSpline< VALUETYPE >, and UE::Geometry::Spline::TPolyBezierSpline< VALUETYPE >.

Friends And Related Symbol Documentation

◆ operator<<

FArchive & operator<< ( FArchive &  Ar,
ISplineInterface &  Spline
)
friend
The documentation for this class was generated from the following file:
