UE::Geometry::TBlockedGrid3Layout< BlockSize_ > Class Template Reference

#include <BlockedLayout3.h>

Inheritance diagram for UE::Geometry::TBlockedGrid3Layout< BlockSize_ >:

Public Types
typedef TBlockData3Layout< BlockSize_ >	FBlockData3Layout

Public Member Functions
	TBlockedGrid3Layout ()
	TBlockedGrid3Layout (int32 DimI, int32 DimJ, int32 DimK)
	TBlockedGrid3Layout (FVector3i Dims)
void	Resize (int32 DimI, int32 DimJ, int32 DimK)
const FVector3i &	GetDimensions () const
const FVector3i &	GetBlockDimensions () const
FAxisAlignedBox3i	Bounds () const
FAxisAlignedBox3i	BoundsInclusive () const
int64	Size () const
bool	IsValidIJK (const FVector3i &IJK) const
bool	IsValidBlockIJK (const FVector3i &BlockIJK)
int32	IJKtoBlockIndex (const FVector3i &IJK) const
void	GetBlockAndLocalIndex (const FVector3i &IJK, int32 &BlockIndexOut, int32 &LocalIndexOut) const
void	GetBlockAndLocalIndex (int32 I, int32 J, int32 K, int32 &BlockIndexOut, int32 &LocalIndexOut) const
FVector3i	BlockIndexToBlockIJK (const int32 BlockIndex) const
int32	BlockIJKToBlockIndex (const FVector3i &BlockIJK) const

Static Public Attributes
static constexpr int32	BlockSize = BlockSize_
static constexpr int32	BlockElemCount = BlockSize * BlockSize * BlockSize

Protected Attributes
FVector3i	BlockDimensions
FVector3i	Dimensions

Member Typedef Documentation

FBlockData3Layout

template<int32 BlockSize_>

typedef TBlockData3Layout<BlockSize_> UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::FBlockData3Layout

Constructor & Destructor Documentation

TBlockedGrid3Layout() [1/3]

template<int32 BlockSize_>

UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::TBlockedGrid3Layout ( )

inline

TBlockedGrid3Layout() [2/3]

template<int32 BlockSize_>

UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::TBlockedGrid3Layout ( int32  DimI, int32  DimJ, int32  DimK  )

inline

TBlockedGrid3Layout() [3/3]

template<int32 BlockSize_>

UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::TBlockedGrid3Layout ( FVector3i  Dims )

inline

Member Function Documentation

BlockIJKToBlockIndex()

template<int32 BlockSize_>

int32 UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::BlockIJKToBlockIndex ( const FVector3i &  BlockIJK ) const

inline

Returns

the block index for the specified block (BlockIJK) in a linearization of the 3d block space.

BlockIndexToBlockIJK()

template<int32 BlockSize_>

FVector3i UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::BlockIndexToBlockIJK ( const int32  BlockIndex ) const

inline

Returns

the 3-d coordinates of the block specified by an index in a linearization of the blocks. BlockIJK is the lattice address of the block in terms of block units ( e.g. the location in a grid of blocks).

Bounds()

template<int32 BlockSize_>

FAxisAlignedBox3i UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::Bounds ( ) const

inline

BoundsInclusive()

template<int32 BlockSize_>

FAxisAlignedBox3i UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::BoundsInclusive ( ) const

inline

GetBlockAndLocalIndex() [1/2]

template<int32 BlockSize_>

void UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::GetBlockAndLocalIndex ( const FVector3i &  IJK, int32 &  BlockIndexOut, int32 &  LocalIndexOut  ) const

inline

return the block index and local index of the cell at (I,J,K).

GetBlockAndLocalIndex() [2/2]

template<int32 BlockSize_>

void UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::GetBlockAndLocalIndex ( int32  I, int32  J, int32  K, int32 &  BlockIndexOut, int32 &  LocalIndexOut  ) const

inline

GetBlockDimensions()

template<int32 BlockSize_>

const FVector3i & UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::GetBlockDimensions ( ) const

inline

Returns

the dimensions of this layout in terms of blocks.

GetDimensions()

template<int32 BlockSize_>

const FVector3i & UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::GetDimensions ( ) const

inline

Returns

the dimensions of this layout in terms of cell ijks.

IJKtoBlockIndex()

template<int32 BlockSize_>

int32 UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::IJKtoBlockIndex ( const FVector3i &  IJK ) const

inline

Returns

the index of the block that holds the cell indicated by IJK.

IsValidBlockIJK()

template<int32 BlockSize_>

bool UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::IsValidBlockIJK ( const FVector3i &  BlockIJK )

inline

Returns

true if the specified block IJK is within the bounds of the block dimensions.

IsValidIJK()

template<int32 BlockSize_>

bool UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::IsValidIJK ( const FVector3i &  IJK ) const

inline

Returns

true if the specified cell IJK is within the bounds of the dimensions.

Resize()

template<int32 BlockSize_>

void UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::Resize ( int32  DimI, int32  DimJ, int32  DimK  )

inline

Recompute the block dimensions required to cover the requested cell dimensions.

Size()

template<int32 BlockSize_>

int64 UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::Size ( ) const

inline

Returns

the number of ijk cells in contained within this grid layout. note: because blocks are 3d pages of fixed size so the number of Blocks X Cells in Block might actually be a larger.

Member Data Documentation

BlockDimensions

template<int32 BlockSize_>

FVector3i UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::BlockDimensions

protected

BlockElemCount

template<int32 BlockSize_>

constexpr int32 UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::BlockElemCount = BlockSize * BlockSize * BlockSize

staticconstexpr

BlockSize

template<int32 BlockSize_>

constexpr int32 UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::BlockSize = BlockSize_

staticconstexpr

Dimensions

template<int32 BlockSize_>

FVector3i UE::Geometry::TBlockedGrid3Layout< BlockSize_ >::Dimensions

protected

---

The documentation for this class was generated from the following file:

• Engine/Source/Runtime/GeometryCore/Public/Spatial/BlockedLayout3.h
