Chaos::FPBDConstraintContainer Class Referenceabstract

#include <PBDConstraintContainer.h>

+ Inheritance diagram for Chaos::FPBDConstraintContainer:

Public Member Functions

CHAOS_API FPBDConstraintContainer (FConstraintHandleTypeID InConstraintHandleType)

virtual CHAOS_API ~FPBDConstraintContainer ()

int32 GetContainerId () const

void SetContainerId (int32 InContainerId)

const FConstraintHandleTypeID & GetConstraintHandleType () const

virtual int32 GetNumConstraints () const =0

virtual void ResetConstraints ()=0

virtual void UpdatePositionBasedState (const FReal Dt)

virtual void PrepareTick ()=0

virtual void UnprepareTick ()=0

virtual void DisconnectConstraints (const TSet< TGeometryParticleHandle< FReal, 3 > * > &)

virtual void OnDisableParticle (FGeometryParticleHandle *DisabledParticle)

virtual void OnEnableParticle (FGeometryParticleHandle *EnabledParticle)

virtual TUniquePtr< FConstraintContainerSolver > CreateSceneSolver (const int32 Priority)=0

virtual TUniquePtr< FConstraintContainerSolver > CreateGroupSolver (const int32 Priority)=0

virtual void AddConstraintsToGraph (Private::FPBDIslandManager &IslandManager)=0


Protected Attributes

FConstraintHandleTypeID ConstraintHandleType

int32 ContainerId


Detailed Description

Base class for containers of constraints. A Constraint Container holds an array of constraints and provides methods to allocate and deallocate constraints as well as the API required to plug into Constraint Rules.

Constructor & Destructor Documentation

◆ FPBDConstraintContainer()

Chaos::FPBDConstraintContainer::FPBDConstraintContainer ( FConstraintHandleTypeID  InConstraintHandleType)

◆ ~FPBDConstraintContainer()

Chaos::FPBDConstraintContainer::~FPBDConstraintContainer ( )
virtual

Member Function Documentation

◆ AddConstraintsToGraph()

virtual void Chaos::FPBDConstraintContainer::AddConstraintsToGraph ( Private::FPBDIslandManager &  IslandManager)
pure virtual

Add all the constraints in the container to the graph

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::FPBDCollisionConstraints, Chaos::FPBDJointConstraints, Chaos::FPBDNullConstraints, Chaos::FPBDPositionConstraints, Chaos::FPBDRigidDynamicSpringConstraints, Chaos::FPBDRigidSpringConstraints, and Chaos::FPBDSuspensionConstraints.

◆ CreateGroupSolver()

virtual TUniquePtr< FConstraintContainerSolver > Chaos::FPBDConstraintContainer::CreateGroupSolver ( const int32  Priority)
pure virtual

Create a constraint solver for an Evolution with Graph support (World evolution). The system will create several of these: usually one per worker thread (Island Group) but possibly more in complex scenes where constraint coloring is being used. It will be used to solve constraints in groups, with the constraints in each group determined by the graph/islands/islandgroups.

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::TPBDIndexedConstraintContainer< ConstaintContainerType >, Chaos::TPBDIndexedConstraintContainer< FPBDNullConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDPositionConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDRigidDynamicSpringConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDRigidSpringConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDSuspensionConstraints >, Chaos::FPBDCollisionConstraints, and Chaos::FPBDJointConstraints.

◆ CreateSceneSolver()

virtual TUniquePtr< FConstraintContainerSolver > Chaos::FPBDConstraintContainer::CreateSceneSolver ( const int32  Priority)
pure virtual

Create a constraint solver for an Evolution without Graph support (RBAN evolution). There will only be one of these per scene (RBAN node) and it is used to solve all constraints in the container (serially).

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::TPBDIndexedConstraintContainer< ConstaintContainerType >, Chaos::TPBDIndexedConstraintContainer< FPBDNullConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDPositionConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDRigidDynamicSpringConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDRigidSpringConstraints >, Chaos::TPBDIndexedConstraintContainer< FPBDSuspensionConstraints >, Chaos::FPBDCollisionConstraints, and Chaos::FPBDJointConstraints.

◆ DisconnectConstraints()

virtual void Chaos::FPBDConstraintContainer::DisconnectConstraints ( const TSet< TGeometryParticleHandle< FReal, 3 > * > &  )
inlinevirtual

Reimplemented in Chaos::FPBDJointConstraints, Chaos::FPBDSuspensionConstraints, and Chaos::FCharacterGroundConstraintContainer.

◆ GetConstraintHandleType()

const FConstraintHandleTypeID & Chaos::FPBDConstraintContainer::GetConstraintHandleType ( ) const
inline

The TypeID of the constraints in this container. Used to safely downcast constraint handles.

See also
FConstraintHandle::As()

◆ GetContainerId()

int32 Chaos::FPBDConstraintContainer::GetContainerId ( ) const
inline

The ContainerId is used to map constraint handles back to their constraint container. Every container is assigned an ID when it is registered - it will be the array index in the Evolution

◆ GetNumConstraints()

virtual int32 Chaos::FPBDConstraintContainer::GetNumConstraints ( ) const
pure virtual

Get the number of constraints in this container (includes inactive and disabled)

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::FPBDCollisionConstraints, Chaos::FPBDJointConstraints, Chaos::FPBDNullConstraints, Chaos::FPBDPositionConstraints, Chaos::FPBDRigidDynamicSpringConstraints, Chaos::FPBDRigidSpringConstraints, and Chaos::FPBDSuspensionConstraints.

◆ OnDisableParticle()

void Chaos::FPBDConstraintContainer::OnDisableParticle ( FGeometryParticleHandle *  DisabledParticle)
virtual

Reimplemented in Chaos::FCharacterGroundConstraintContainer.

◆ OnEnableParticle()

void Chaos::FPBDConstraintContainer::OnEnableParticle ( FGeometryParticleHandle *  EnabledParticle)
virtual

Reimplemented in Chaos::FCharacterGroundConstraintContainer.

◆ PrepareTick()

virtual void Chaos::FPBDConstraintContainer::PrepareTick ( )
pure virtual

Called oncer per tick to initialize buffers required for the rest of the tick

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::FPBDCollisionConstraints, Chaos::FPBDJointConstraints, Chaos::FPBDNullConstraints, Chaos::FPBDPositionConstraints, Chaos::FPBDRigidDynamicSpringConstraints, Chaos::FPBDRigidSpringConstraints, and Chaos::FPBDSuspensionConstraints.

◆ ResetConstraints()

virtual void Chaos::FPBDConstraintContainer::ResetConstraints ( )
pure virtual

Empty the constraints (must be removed from the graph first, if required)

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::FPBDCollisionConstraints, Chaos::FPBDJointConstraints, Chaos::FPBDNullConstraints, Chaos::FPBDPositionConstraints, Chaos::FPBDRigidDynamicSpringConstraints, Chaos::FPBDRigidSpringConstraints, and Chaos::FPBDSuspensionConstraints.

◆ SetContainerId()

void Chaos::FPBDConstraintContainer::SetContainerId ( int32  InContainerId)
inline
See also
GetContainerId()

◆ UnprepareTick()

virtual void Chaos::FPBDConstraintContainer::UnprepareTick ( )
pure virtual

Should undo any allocations in PrepareTick

Implemented in Chaos::FCharacterGroundConstraintContainer, Chaos::FPBDCollisionConstraints, Chaos::FPBDJointConstraints, Chaos::FPBDNullConstraints, Chaos::FPBDPositionConstraints, Chaos::FPBDRigidDynamicSpringConstraints, Chaos::FPBDRigidSpringConstraints, and Chaos::FPBDSuspensionConstraints.

◆ UpdatePositionBasedState()

virtual void Chaos::FPBDConstraintContainer::UpdatePositionBasedState ( const FReal  Dt)
inlinevirtual

An opportunity to create/destroy constraints based on particle state.

Reimplemented in Chaos::FPBDPositionConstraints, and Chaos::FPBDRigidDynamicSpringConstraints.

Member Data Documentation

◆ ConstraintHandleType

FConstraintHandleTypeID Chaos::FPBDConstraintContainer::ConstraintHandleType
protected

◆ ContainerId

int32 Chaos::FPBDConstraintContainer::ContainerId
protected
The documentation for this class was generated from the following files:
